CPCI-48IN
CPCI 48 Input I/O Card with FPGA based I/O Controller
- Based on FPGA I/O controllers for input monitoring
- CompactPCI module
- Front panel I/O
- 48 inputs optically isolated
- Isolated to 2500V
- Input resistance at 2.5KΩ @ 1/4W
- Input options: 5, 12, 24, 30, 48
- Logic 0 – 3V Max, Logic 1 – 5V and above
- Less than 100μs Opto Isolator response
- Interrupt on: level low to high, high to low transitions
- Patterns match interrupt
- MTBF > 200,000 hours
Share this product
LinkedIn
CPCI-48IN
CPCI 48 Input I/O Card with FPGA based I/O Controller
The input board consists of three I/O controllers for DC input control. An FPGA provides the timing and control. Each input has its own optical isolation and supports a hardware-adjustable resistor/opto-diode combination for various input voltage ranges. A PLX 9056 PCI controller provides the interface to the host computer. All I/O is accessible from the front panel.
Available Software Drivers and Tools:
- C library DLLs
- Windows and Linux drivers available
Applications
The input board is used in industrial applications where there is a need to control devices such as LEDs, lamps, relays, contactors, etc. Full output system isolation is provided up to 2500V/channel.
I/O Features
- Two independent 8-bit, double-buffered bidirectional I/O ports
- I/O ports feature programmable polarity
- Programmable direction at the bit level
- Flexible pattern-recognition logic; programmable as a 16-bit vector interrupt controller
- Three independent 16-bit counter/timers with up to four external access lines per counter/timer
- Four handshake modes
- All internal registers are readable and writable
- All registers have their own unique address so that they can be accessed directly
PCI Bus Controller Features
- PLX 9056 33/66MHz 32-bit, PCI r2.2 compliant
- Motorola PowerQUICC and generic 32-bit, 66MHz local bus modes
- 3.3V I/O, 5V tolerant bus interfaces
- PICMG 2.1 r2.0 hot swap
- Zero wait state burst operation, with PCI bus bursts to 264 MB/sec and local bus bursts to 264 MB/sec
- 2 DMA channels
- Direct master data transfers
- Direct slave data transfers
I/O Specifications
- 48 input pins, front panel accessible
- SCSI style front panel connector
- Input current and the input threshold are a function of the hardware-adjustable resistor and the input voltage range
- 4.7K 4V to 30V input 3V threshold
- 10K 7.5V to 44V input 5.4V threshold
- 20K 14V to 60V input 9.8V threshold
- Optically isolated to 2500 VDC
Operating Environment
- Operating temperature: Commercial – 0 to +70°C, Optional – -40°C to +85°C
- Non-operating: -50°C to +90°C
- Airflow requirement – 5 CFM
- Humidity – 5 to 90% (non-cond)
- Altitude – 0 to 10,000 feet
Mechanical Environment
- Size – 3U CPCI module, 100mm x 160mm
- Power – 1.5 watt
- Vibration – 0.5G, 20-2000 Hz random
- Shock – 20G, 11 msec, 1⁄2 sine
- Weight – 4 ounces
- MTBF – >250,000 hours
CPCI-48IN-1 48 channel input; optically isolated; 4-30V input range
CPCI-48IN-2 48 channel input; optically isolated; 7.5-44V input range
CPCI-48IN-3 48 channel input; optically isolated; 14-60V input range
Optional Accessories
TB-100 Terminal block and cable
CBL-100 100 pin cable only
- Based on FPGA I/O controllers for input monitoring
- CompactPCI module
- Front panel I/O
- 48 inputs optically isolated
- Isolated to 2500V
- Input resistance at 2.5KΩ @ 1/4W
- Input options: 5, 12, 24, 30, 48
- Logic 0 – 3V Max, Logic 1 – 5V and above
- Less than 100μs Opto Isolator response
- Interrupt on: level low to high, high to low transitions
- Patterns match interrupt
- MTBF > 200,000 hours
| Mechanical Interface | Switched Mezzanine Card (XMC) Interface confirming to ANSI/VITA 42.0-2008 (Auxiliary Standard) Standard single-width (149mm x 74mm) | |||||||||
| Electrical Interface | PCI Express x4 Link (Base Specification 2.1) compliant interface conforming to ANSI/VITA 42.3-2006 (PCI Express Protocol Layer Standard) | |||||||||
| PCI Express Switch | PI7C9X2G312GP (Pericom) | |||||||||
| PCI Express to PCI Bridge | XIO2001 (Texas Instruments) | |||||||||
| User configurable FPGA | TXMC639-10R: XC7K160T-2FBG676I (AMD) TXMC639-11R: XC7K325T-2FBG676I (AMD) | |||||||||
| SPI-Flash | MT25QL128 (Micron) 128 Mbit (contains TXMC639 FPGA BRD) or compatible; +3.3 V supply voltage | |||||||||
| DDR3 RAM | 2x MT41K256M16TW-107 (Micron) 256Meg x 32 bit | |||||||||
| Board Configuration Controller | LCMXO2-7000HC (Lattice) | |||||||||
| ADC | LTC2320 -16 (Analog Devices) | |||||||||
| DAC | AD5547BRUZ (Analog Devices) | |||||||||
| A/D Channels | TXMC639-10R: 8 Differential 16bit A/D Channels TXMC639-11R: 16 Differential 16bit A/D Channels Input Configuration per BCC Device: Input Voltage Ranges: Differental : ±20.57 V, ±10.28 V or ±5.14 V (Single-Ended: ±10.28 V, ±5.14 V or ±2.57 V) All analog inputs are connected via an impedance converter and a second operation amplifier for level adjustment and filtering to the differential ADC inputs. The -3 dB limit of this input stage is at approx. 8MHz | |||||||||
| D/A Channels | TXMC639-10R: 4 Single-Ended 16 Bit D/A Channels TXMC639-11R: 8 Single-Ended 16 Bit D/A Channels Output range configurable per D/A channel. Maximum single-ended Output Voltage – Vout: ±10 V Maximum Output Drive Current for each Output: 10 mA Maximum Capacitive Load for each Output: 1000 pF Typical Settling Time for a 10 mA / 1000 pF: < 1 µs | |||||||||
| Digital Front I/O Channels | 32 digital I/O Lines
| |||||||||
| Digital Rear I/O Channels | 64 direct FPGA I/O lines to P14 Rear I/O connector
4 MGT line to P16 Rear I/O connector
| |||||||||
| Front I/O | Front I/O Samtec – ERF8_050_01_L_D_RA_L_TR | |||||||||
| P14 Rear I/O | 64 pin Mezzanine Connector (Molex 71436-2864 or compatible) | |||||||||
| P16 Rear I/O | 114 pin Mezzanine Connector (Samtec – ASP-105885-01) | |||||||||
| Power Requirements 1) | Depends on FPGA design With TXMC639 Board Reference Design / without external load
| |||||||||
| Temperature Range | Operating: – 40 °C to + 85 °C Storage: – 55 °C to + 125 °C | |||||||||
| MTBF 1) | 157 000 h to 161 000 h | |||||||||
| Humidity | 5% – 95% non-condensing | |||||||||
| Weight | 140 g |
1) depends on variant, for further details see User Manual
TXMC639-10R
| 8x Analog In, 4x Analog Out, XC7K160T-2FBG676 Kintex™ 7 FPGA AMD Kintex™ 7 FPGA (XC7K160T-2FBG676), 1GB DDR3, 8x Analog In, 4x Analog Out, 32x digital Front I/O, 64x direct FPGA Rear I/O Lines and 4x MGTs Rear I/O |
TXMC639-11R
| 16x Analog In, 8x Analog Out, XC7K325T-2FBG676 Kintex™ 7 FPGA AMD Kintex™ 7 FPGA (XC7K325T-2FBG676), 1GB DDR3, 16x Analog In, 8x Analog Out, 32x digital Front I/O, 64x direct FPGA Rear I/O Lines and 4x MGTs Rear I/O |
