IP-SYNCHRO

Dual Channel 16 bit Synchro / Resolver Industry Pack Module

  • Converter Type: Dual channel Resolver/Synchro to digital converters
  • Programmable Resolution: 10, 12, 14, and up to 16-bit
  • Tracking Rate: Up to 1152 rps
  • Reading Capability: Simultaneous reading of the converters
  • On-Board Excitation: Available with oscillator output ~1 Vrms
  • Programmable Frequency Excitation: 50, 60, 400, 1k, 2.5k, 5k, 10 k Hz
  • User-Defined Excitation Voltage: Options include 2.2, 2.5, 4, 4.4 Vrms
  • Converter Error Conditions: Monitored on board
  • Reference Synthesis: On-board synthesized reference

Share this product

LinkedIn

Got Questions?

IP-SYNCHRO

Dual Channel 16 bit Synchro / Resolver Industry Pack Module

  • Converter Type: Dual channel Resolver/Synchro to digital converters
  • Programmable Resolution: 10, 12, 14, and up to 16-bit
  • Tracking Rate: Up to 1152 rps
  • Reading Capability: Simultaneous reading of the converters
  • On-Board Excitation: Available with oscillator output ~1 Vrms
  • Programmable Frequency Excitation: 50, 60, 400, 1k, 2.5k, 5k, 10 k Hz
  • User-Defined Excitation Voltage: Options include 2.2, 2.5, 4, 4.4 Vrms
  • Converter Error Conditions: Monitored on board
  • Reference Synthesis: On-board synthesized reference

The IP-SYNC-x Industry Pack module from Alphi Technology is a dual-channel Resolver/Synchro to digital converter module. It incorporates two independent R/D/C controllers, each capable of handling different input configurations such as direct, differential, resolver, or synchro. This module is designed for applications in radar, antenna positioning, scientific research, laboratory settings, medical equipment, and machine control. The tracking rate and bandwidth are user-defined during the ordering process, allowing for customization based on specific application requirements. The module is compatible with the VITA 4 1995 specification, ensuring compatibility with a wide range of systems.

I/O Level
  • Direct input for 2V resolver Differential
  • Synchro input (predefined : 11.8V or 90V)
  • (2) DDC RDC19222 controller
IP Interface
  • 8/32 Mhz clock
Mechanical & Environmental
  • Operating temperature
    • Commercial: 0 to +55 °C
    • Optional: -25°C to +80°C
  • Airflow requirement: .5 CFM
  • Humidity: 5 to 90% (non-cond.)
  • Altitude: 0 to 10’000 ft
  • Size: Vita 4 Type 1 IP 1.8″ x 3.9″
  • Power: .7 watt
  • Vibration: 0.5G RMS 20-2000 Hz rand
  • Shock: 20 G, 11 ms, 1⁄2 sine
  • MTBF: >110000 hours

Part Number : IP-SYNCHRO-2

IP-SYNCHRO-11

IP-SYNCHRO-90

Optional Accessories

Part Number : TB-50-HDR 50 pin terminal block and 1meter flat ribbon cable

Part Number : CBL-50-HDR 50 pin 1meter flat ribbon cable, IDC header connector

Data Sheet – Link Here

User Manual – Link Here

  • Converter Type: Dual channel Resolver/Synchro to digital converters
  • Programmable Resolution: 10, 12, 14, and up to 16-bit
  • Tracking Rate: Up to 1152 rps
  • Reading Capability: Simultaneous reading of the converters
  • On-Board Excitation: Available with oscillator output ~1 Vrms
  • Programmable Frequency Excitation: 50, 60, 400, 1k, 2.5k, 5k, 10 k Hz
  • User-Defined Excitation Voltage: Options include 2.2, 2.5, 4, 4.4 Vrms
  • Converter Error Conditions: Monitored on board
  • Reference Synthesis: On-board synthesized reference



Mechanical Interface

Switched Mezzanine Card (XMC) Interface confirming to ANSI/VITA 42.0-2008 (Auxiliary Standard)

Standard single-width (149mm x 74mm)

Electrical InterfacePCI Express x4 Link (Base Specification 2.1) compliant interface conforming to ANSI/VITA 42.3-2006 (PCI Express Protocol Layer Standard)
PCI Express SwitchPI7C9X2G312GP (Pericom)
PCI Express to PCI BridgeXIO2001 (Texas Instruments)
User configurable FPGA

TXMC639-10R: XC7K160T-2FBG676I (AMD)

TXMC639-11R: XC7K325T-2FBG676I (AMD)

SPI-FlashMT25QL128 (Micron) 128 Mbit (contains TXMC639 FPGA BRD) or compatible; +3.3 V supply voltage
DDR3 RAM2x MT41K256M16TW-107 (Micron) 256Meg x 32 bit
Board Configuration ControllerLCMXO2-7000HC (Lattice)
ADCLTC2320 -16 (Analog Devices)
DACAD5547BRUZ (Analog Devices)
A/D Channels

TXMC639-10R: 8 Differential 16bit A/D Channels

TXMC639-11R: 16 Differential 16bit A/D Channels

Input Configuration per BCC Device:

Input Voltage Ranges:

Differental : ±20.57 V, ±10.28 V or ±5.14 V

(Single-Ended: ±10.28 V, ±5.14 V or ±2.57 V)

All analog inputs are connected via an impedance converter and a second operation amplifier for level adjustment and filtering to the differential ADC inputs.

The -3 dB limit of this input stage is at approx. 8MHz

D/A Channels

TXMC639-10R: 4 Single-Ended 16 Bit D/A Channels

TXMC639-11R: 8 Single-Ended 16 Bit D/A Channels

Output range configurable per D/A channel.
Simultaneous Conversion for all D/A Channels.

Maximum single-ended Output Voltage – Vout: ±10 V

Maximum Output Drive Current for each Output: 10 mA

Maximum Capacitive Load for each Output: 1000 pF

Typical Settling Time for a 10 mA / 1000 pF: < 1 µs

Digital Front I/O Channels

32 digital I/O Lines

  • Default configured as 32 ESD-protected TTL lines
  • 16 I/O lines are configurable as 8 differential RS422 I/O lines with individual Termination enable.
Digital Rear I/O Channels

64 direct FPGA I/O lines to P14 Rear I/O connector

  • Can be used as single-ended or differential I/O
  • FPGA I/O Standard: LVCMOS25, LVTTL25 and LVDS25

4 MGT line to P16 Rear I/O connector

  • Each line consists of one differential RX and TX pair.
  • Transmission speeds of up to 3.125 Gb/s are possible.
Front I/OFront I/O Samtec – ERF8_050_01_L_D_RA_L_TR
P14 Rear I/O64 pin Mezzanine Connector (Molex 71436-2864 or compatible)
P16 Rear I/O114 pin Mezzanine Connector (Samtec – ASP-105885-01)
Power Requirements 1)

Depends on FPGA design

With TXMC639 Board Reference Design / without external load

 typical @ +12 V VPWRtypical @ +5 V VPWR
TXMC639-10R1.1 A2.5 A
TXMC639-11R1.3 A3.3 A
Temperature RangeOperating: – 40 °C to + 85 °C
Storage: – 55 °C to + 125 °C
MTBF 1)157 000 h to 161 000 h
Humidity5% – 95% non-condensing
Weight140 g

1) depends on variant, for further details see User Manual



TXMC639-10R



8x Analog In, 4x Analog Out, XC7K160T-2FBG676 Kintex™ 7 FPGA

AMD Kintex™ 7 FPGA (XC7K160T-2FBG676), 1GB DDR3, 8x Analog In, 4x Analog Out, 32x digital Front I/O, 64x direct FPGA Rear I/O Lines and 4x MGTs Rear I/O

TXMC639-11R



16x Analog In, 8x Analog Out, XC7K325T-2FBG676 Kintex™ 7 FPGA

AMD Kintex™ 7 FPGA (XC7K325T-2FBG676), 1GB DDR3, 16x Analog In, 8x Analog Out, 32x digital Front I/O, 64x direct FPGA Rear I/O Lines and 4x MGTs Rear I/O

SOFTWARE

Device Driver for Board Family with Reconfigurable FPGA

Data Sheet – Link-Here

User Manual – Link-Here
